The JBL EON510 is a 10", 2-way, powered portable speaker system. Capable of reproducing full-bandwidth sound at high levels, it offers the additional utility of a 3-channel built-in mixer. The EON510 is comprised of a 10" Differential Drive woofer, a 1" neodymium high-frequency compression driver coupled to a 100° H by 60° V waveguide. Both components are driven by the discrete channels of a 280-watt Class D integrated power amplifier. The PA speaker's input section contains all crossover functions, protection, and mixer functionality.
280W high-performance powered speaker system
Ultra-Lightweight and extremely compact
Soft-touch top grip for easy handling.
10" Differential Drive low-frequency driver with neodymium magnet for low distortion and light weight
1" throat diameter next generation JBL neodymium compression driver
Efficient Class-D digital amplifier technology
Built-in 3-Channel Mixer
100° H x 60° V asymmetrical waveguide for uniform audience coverage
Line level and direct microphone input capability
Selectable pre-engineered EQ settings
Unique Mix/Loop signal flow function for extended system application
Easy "daisy-chain" connections for extending the system
Integrated M10 suspension points for easy rigging
Multi-angle enclosure for main or monitor applications
Integrated 36 mm pole-mount socket with stabilizing securing screw
Composite enclosures designed to be durable, lightweight
Retrostar Music is an Authorized Dealer of JBL products.
