CMOS Pan tilt CMOS IP Camera network camera cctv camera

CMOS Pan tilt CMOS IP Camera network camera cctv camera

Specs:

Model No.
EC-IP2628

Camera Type
Pan tilt CMOS IP Camera

CPU
Operation system
Embedded Linux OS

processor
32Bit RSIC Embedded Processor

Video
Compression format
Motion-JPEG-N

Signal system
CMOS 300,000 pixel

Frame Rate
25fps PAL 30fps NTSC

Resolution
VGA(640*480),QVGA(320*240)

Video Adjustment
brightness, contrast, chroma, saturation.

Mini illumination
0.1 Lux/F1.2

S/N ratio
>48DB (AGC off)

shutter speed
1/50s(1/60s) ~ 1/100,000 s

WB/BCL
Auto

Lens
standard-3.6mm Optional-6mm 8mm

nightvision
night vision
Φ5 10 LED light the night vision is 10m

Audio Gain
(AGC)

Audio
processor
Have the two-way pronunciation sound processor built-in,Support sound monitoring

Audio gain
Auto Audio Gain control (AGC)

rotating Control
electronic motor
electronic motor control inside

Revolution angle
Level direction-220°,Perpendicularity direction-90°

Revolution speed
level-15°/ Second Perpendicularity;15°/second

Network
Network interface
RJ-45 10/100Mb self-adaptable Ethernet slot

Protocol
Support TCP/IP,HTTP,ICMP,DHCP,FTP,SMTP,PPPoE etc.

Wireless
WIFI,802.11 b/g

Simultanious visitor
Support 5 direct visitors at the same time,but no limitation when using forwarder Server.

IP mode
Dynamic IP address,Static IP address,PPPOE

Alarm
Input / Output
1ch Input 1ch Output

Motion detection
Motion Detection setting

Alarm action
support email,message, etc. alarm

System
System requirement
Microsoft Win2000/XP,Vista, IE 5.0, NET4.5 or above

Features
Security Settings
two-level password/ administrator authority, user authority

DDNS(free)
Free DDNS bounded i.e

superiority
P2P technology, mobile view

Center management system(free)
1,4,9,16,25,36 or 64 multiple video display optional in one screen, support record, alarm, remote playback on records and other management functions.

Others
shape
cartoon robot

Using Environments
indoor use

power
DC5V 2A

Temperature
-10~50 °C

Humidity
95% RH

Attachment
Adaptor, CD(including introduction), Manual, bracket

Dimensions
item size-91mm x 103mm x 135mm (LxWxH)

packaging size-170mm x 170mm x 170mm (LxWxH)

Weight
Net-0.35KG Gross-.65KG


-------------------------------------------------------------
