Raritan Rack Transfer Switches PX3TS-1876CR-N1 - power control unit - 3800

Raritan's innovative hybrid rack transfer system provides industry leading performance and maximum reliability. Traditional automatic transfer switches (ATS) suffer from longer transfer times of 8 to 16 ms, and often fail as a result of electrical arcing that welds contacts together. Static transfer switches (STS) offer very fast transfers of 4 to 6 ms, but are over five and half times more expensive than ATS, draw far more energy and produce excess heat.Raritan's hybrid transfer switch cleverly uses both electromechanical relays and silicon-controlled rectifiers (SCRs) to maximize the positive and minimize the negative characteristics of each.Power SupplyDevice Output Connector Type:Power IEC 320 EN 60320 C13 , Power IEC 320 EN 60320 C19CableConnectivity Details Length:10 ftConnectivity Details Type:Power cableEnvironmental ParametersHumidity Range Operating:5 - 85%Max Operating Temperature:140 °FMin Operating Temperature:41 °FHeaderBrand:RaritanCompatibility:PCManufacturer:RaritanModel:PX3TS-1876CR-N1Packaged Quantity:1Product Line:Raritan Rack Transfer SwitchesInterface ProvidedConnector Type:RJ-45Qty:1Type:LANConnector Type:9 pin D-Sub (DB-9)Type:ManagementConnector Type:4 pin USB Type AType:ModemConnector Type:RJ-12Type:MonitoringType:USBConnector Type:4 pin USB Type BMiscellaneousColor:Black powder coatColor Category:BlackCompliant Standards:cULus , ICES-003 , RoHS , UL , UL 60950-1Height (Rack Units):1NetworkingRemote Management Interface:Ethernet 10/100 , RS-232 , USBRemote Management Protocol:HTTP , HTTPS , SNMP , SNMP 2 , SNMP 3 , TelnetPower DeviceCircuit Protection:FuseForm Factor:Rack-mountableFrequency Required:50/60 HzInput Connector Qty:2Input Connector Type:Power IEC 320 EN 60320 C20Input Voltage Range:AC 200 - 240 VInput Wiring:1-phaseMax Electric Current:16 AOutput Connector Qty:9Power Capacity (VA):3800 VAPower Device Features:Active power meter , Amp meter , Energy meter , LED display , Power factor meter , Voltage monitoringPower Output Connectors DetailsConnector Qty:8Connector Type:Power IEC 320 EN 60320 C13Current:12 AConnector Qty:1Connector Type:Power IEC 320 EN 60320 C19Current:16 ADimensions & WeightDepth:15 inHeight:1.7 inWidth:17.3 inTitleRaritan Rack Transfer Switches PX3TS-1876CR-N1 - power control unit - 3800ConditionNew, open boxContentRaritan Rack Transfer Switches PX3TS-1876CR-N1ManufacturerRaritanModelPX3TS-1876CR-N1SKUSIRT001 #1092_90UPC0785813026545http://www.compeve.com/Products/PDU/Raritan/PX3TS-1876CR-N1/PX3TS-1876CR-N1_compeve__1.jpghttp://www.compeve.com/Products/PDU/Raritan/PX3TS-1876CR-N1/PX3TS-1876CR-N1_compeve__2.jpg
