Support 100 fingerprints / 200 ID Cards / 1 groups password
Universal for Right or Left direction and Push or Pull opening

Specifications:
Brand: NSEE
Model: R-FZ3
Material: Stainless steel
Unlock mode: Fingerprint +Password+ID card + Key
Card User: 200
Fingerprint User: 100
Password: 1 Groups
Fingerprint read: RF sensor
Color: Red Bronze/Gold/Silver/Black
Chip Type: Dual Core Driver
Chip level: C level
Read time: less than 1 seconds
Touch screen: Tempering glass
Working power: 4 x AA batteries
Operating temperature: -25 to 65°C
Password function: support virtual password
Suit for the door thickness about 37-100mm

Manage Card:
Operate the lock by the manage card (adding fingerprint / ID card / setting password)

Fingerprint Unlocking:
Max support 100pcs fingerprint registering.

RFID Card Unlock:
The card was encrypted that is prevent copying,so if you need more cards please contact us.

Max support 200pcs registering.

Password Unlocking:
Support 6 digits password.

You can input any number before or after correct password (Guard against peeping)

Continuously input the wrong password 5 times,the keypad will be locked 5 minutes (More Security)

Locked & Unlock by the handle up and down:
There is a inside locked device on the back side.

Battery Jar:
In the front of the lock.If the battery no have any power,you can replace the battery from outdoor.

How to open the battery jar,please follow this picture.

Hidden Keyhole:
It is the backup unlock key.

Please uncover the cover with magnetic that can see the keyhole.

Lock Cylinder and keys:
With anti mechanical violence,only real cylinder can real anti-thief

Class C lock cylinder is manufactured according to the safety standard of national .The key adopts double side double row with inner grooves + side marble design,and the inner of lock cylinder adopts multi track double marbles.The anti drilling experiments have exceeded the national C level lock core standards.Higher security factor,better user experience.The technical open time is two times of class B lock cylinder,and even can not open,fully beyond the B level lock more.
