Features:


1. Manual release device to operate the barrier when power off.

2. Motor cooling fan to avoid the over-heating possibility

3. Automatic reversing when the barrier boom meets the obstruction

4. Auto closing realization through menu setting on the control panel

5. Interfaces available for infrared photocells, loop detectors, card readers, ticket dispensers, manual switch (wire control), traffic light

6. RS485 Communication Module is compatible

Technical data:


1. Working temperature:-40~+75 degree centigrade.

2. Power: 220V±10%, 110V±10%, 50/60HZ

3. Rated power: 80W

4. Relative humidity: ≤90%

5. Remote control distance: ≥30m

6. Net weight: 56kgs

7. Speed: 1S, 3S, 6S

8. Protection Class: IP54

When purchasing please leave us a note about the opening speed, voltage and the installation position (taking a look from the front position)

- Opening speed (1, 3 or 6 seconds to be fully opened)

- Open to the left or open to the right

- Voltage (could be 110v or 220v, if no message is left we will send depending on the customer country standard voltage)


Package Included:

1. Remote control (2 pcs)

2. Articulated arm (3m)

3. Control board

4. Installation hardware

5. Manual
